JBL PartyBox On-the-Go 2 Plus

General Specifications

Output power

100 W RMS (IEC60268)

Power input

100 – 240 V ~50/60 Hz

Audio Specifications

Frequency response

40 Hz – 20 kHz (-6 dB)

Transducer

Transducer 2 x 0.75 inch (20 mm) Dome tweeters

1 x 5.25 inch (135 mm) woofer; Tweeter

Signal-to-noise ratio

> 80dB

Dimensions

Product dimensions (W x H x D)

501 mm x 258 mm x 221 mm / 19.72 x 10.16 x 8.70

Net weight

6.45 kg / 14.22 lbs

Packaging dimensions (W x H x D)

586 mm x 355 mm x 278 mm / 23.07 x 13.98 x 10.94

Gross weight

9.27 kg / 20.44 lbs

Control and Connection Specifications

USB charge out

11 V / 2 A (Max) (Speaker off mode)

USB file format

FAT16, FAT32

USB playback formats supported (Disable for EMEA region)

.MP3, .WAV, .FLAC

Bluetooth? version

5.4

Bluetooth? profile

A2DP V1.4, AVRCP V1.6 (SW), TMAP1.0, PBP1.0

Bluetooth? transmitter frequency range

2.4 GHz – 2.4835 GHz

Bluetooth? transmitter power

≤ 16 dBm (EIRP)

Bluetooth? transmitter modulation

GFSK, π/4 DQPSK, 8DPSK

2.4G wireless transmitter frequency range

2404 – 2478 MHz

2.4G wireless transmitter power

< 10 dBm (EIRP)

2.4G wireless modulation

GFSK

Aux-In

370 mV RMS (3.5mm connector)

Mic-In

20 mV RMS

Bluetooth/USB input

-9dBFS

Battery

Power Cable type

AC power cable (type varies by regions)

AC Cable length

2.0m / 6.6 ft

Battery type

Li-ion 34 Wh (7.2 V / 4722 mAh)

Battery charge time

< 3.5 hours (Speaker off mode)

Music play time

up to 15 hours (varies by volume level and audio content)
